• Cooling capacity rendered 3389 (W/f) for chamber volume 37,6 m³ / 37600 Lit. (T° internal 0° C & T° external +32° C).
• Refrigerant expansion by capillary.

• "Overlapping" refrigeration units.
• Unit certified in climatic class 5 (40°C Temperature - 40% Humidity).
• All units are supplied as standard with a high pressure switch and KVL valve.
• Automatic hot gas defrost with self-evaporation and overflow.
• The evaporator drain pipe is equipped with a resistor to prevent ice formation.
• Refrigerant gas R452a.
• Supplied with cables and micro-switch for door and light (Porthole lights supplied as standard).
• Microprocessor control with touch-sensitive keys.

INFO:
Attention: As standard, the ideal ambient operating temperature cannot be lower than 10°C, otherwise, provide: a compressor preheating (A-PR-R), a pressure switch for the condenser fan (A-PVC-R) as well as a heated electrical panel (A-TEC-R). In this case, the operating temperature cannot be lower than -5°C. The unit must be protected from the weather when installed outdoors.

PLUS:

• Groups of 400mm length with small dimensions, possible placement on all our chambers (minimum 600mm panel).
• All groups are supplied with a high pressure switch as standard. The negative groups are equipped with a thermostatic valve.
