For motor type: 7/7/14 - 9/9/9 - 9/9/14 - 10/10/9 - 10/10/14. On/Off switch and potentiometer speed variator On/Off lighting switch.
Manufactured in stainless steel 18/10 AISI 304. Invisible sides in stainlees steel AISI 430. Sides "point" welded. 6 stainless steel filters "labyrinth". Peripherically welded fat catching canal. Evacuation tap beneath. Built-in neon lighting "IP65".
Realization polycarbonate. Conceived for high temperatures (65°C). Lower hiding place transparent fixed with clips facilitating the dismantling for the maintenance. Delivered with a lamp TL (18 Watt).
Profile frame in aluminium. Panels with isolated double wall. Lateral inspection. Ventilator with belt drive, 2 speed levels. 3 double filtering.
2 labyrinths filters ANTI GREASE (2x 400x500 mm) Model with built-in centrifugal fan "watertight" (IP55) incorporated, low energy "Energy Saving". Electric case (central position, in vertical). Designed in stainless steel AISI 441, assembly by points welding. Filters anti-fat has stainless steel labyrinths AISI 430. Peripheral channel for the fat collection, fitted with a drainage tap. Built-in lighting (TL) waterproof (IP65), high temperature. Speed regulator built-in the frontal.
For engine ventilator of type: 10/10/0,75 - 10/10/1,1 - 10/10/1,5 - 12/12/1,5 - 12/12/2,2 Fuses of protection for the safety of the engine. Compound casket of: * Switch one / off ( 2 speeds) coupled with a warning light,* Switch one / off, lighting coupled with a warning light,* Lock with key.- Metallic casket seals IP55.
Frame in galvanized steel. Soundproof isolation.
Manufactured in stainless steel 18/10 AISI 304, finished with flattened folds. Invisible sides in stainlees steel AISI 430, sides completely welded. Isolated room for fresh air supply to prevent condense. Regulator from volume of fresh air supply. 3 stainless steel filters "labyrinth" 500x500 mm. Peripherically welded fat catching canal. Evacuation tap beneath. Built-in neon lighting "IP65".
Manufactured in stainless steel 18/10 AISI 304, finished with flattened folds. Invisible sides in stainlees steel AISI 430, sides completely welded. Isolated room for fresh air supply to prevent condense. Regulator from volume of fresh air supply. 6 stainless steel filters "labyrinth" 400x400 mm. Peripherically welded fat catching canal. Evacuation tap beneath. Built-in neon lighting "IP65".
For motor type: 12/9/9 - 12/12/9. On/Off switch and potentiometer speed variator. On/Off lighting switch.
Manufactured in stainless steel 18/10 AISI 304. Invisible sides in stainlees steel AISI 430. Sides "point" welded. 6 stainless steel filters "labyrinth". Peripherically welded fat catching canal. Evacuation tap beneath. Built-in neon lighting "IP65".
Realization polycarbonate. Conceived for high temperatures (65°C). Lower hiding place transparent fixed with clips facilitating the dismantling for the maintenance. Delivered with a lamp TL (36 Watt).
Profile frame in aluminium. Panels with isolated double wall. Lateral inspection. Ventilator with belt drive, 2 speed levels. 3 double filtering.
3 Filters ANTI-FAT labyrinths (2x 400x500 & 1x 500x500 mm) Model with built-in centrifugal fan "watertight" (IP55) incorporated, low energy "Energy Saving". Electric case (central position, in vertical). Designed in stainless steel AISI 441, assembly by points welding. Filters anti-fat has stainless steel labyrinths AISI 430. Peripheral channel for the fat collection, fitted with a drainage tap. Built-in lighting (TL) waterproof (IP65), high temperature. Speed regulator built-in the...
For engine ventilator of type: 10/10/0,75 - 10/10/1,1 - 10/10/1,5 - 12/12/1,5 - 12/12/2,2 Fuses of protection for the safety of the engine. Compound casket of: * Switch one / off ( 2 speeds) coupled with a warning light,* Switch one / off, lighting coupled with a warning light,* Lock with key.- Metallic casket seals IP55.
Frame in galvanized steel. Soundproof isolation.
Manufactured in stainless steel 18/10 AISI 304, finished with flattened folds. Invisible sides in stainlees steel AISI 430, sides completely welded. Isolated room for fresh air supply to prevent condense. Regulator from volume of fresh air supply. 3 stainless steel filters "labyrinth" 500x500 mm. Peripherically welded fat catching canal. Evacuation tap beneath. Built-in neon lighting "IP65".
Manufactured in stainless steel 18/10 AISI 304, finished with flattened folds. Invisible sides in stainlees steel AISI 430, sides completely welded. Isolated room for fresh air supply to prevent condense. Regulator from volume of fresh air supply. 6 stainless steel filters "labyrinth" 400x400 mm. Peripherically welded fat catching canal. Evacuation tap beneath. Built-in neon lighting "IP65".
Manufactured in stainless steel 18/10 AISI 304. Invisible sides in stainlees steel AISI 430. Sides "point" welded. 6 stainless steel filters "labyrinth". Peripherically welded fat catching canal. Evacuation tap beneath. Built-in neon lighting "IP65".
Realization polycarbonate. Conceived for high temperatures (65°C). Lower hiding place transparent fixed with clips facilitating the dismantling for the maintenance. Delivered with a lamp TL (58 Watt).
Profile frame in aluminium. Panels with isolated double wall. Lateral inspection. Ventilator with direct suction. 3 double filtering.
